NMD90 XLPE AL Wire
Standard: CSA C22.2 No.48(non-metallic sheathed cable)
Working temperature: in dry locations only at temperature not to exceed 90°C.
Performance:FT-1 Flame retardant; Heat and moisture-resistant
Structure
- Conductor: Aluminium alloy 8000series ACM with AL grounding wire Grey 6AWG to 2AWG.
- Insulation: Crosslinked polyethylene (XLPE)
- Jacket: PVC, Heat and moisture-resistant, flame retardant FT1.
- Number of Conductor: 3 and 4 round laid
Application
NMD90 cables may be used for both exposed work in dry locations or concealed work in dry or damp locations. The maximum allowable conductor temperature is 90°C. The minimum recommended installation temperature is -25°C or -40°C for two-conductor cables and -25°C for three-conductor cables (with suitable handling procedures). Material should be properly stored above 0°C for 24 hours prior to installation. The maximum voltage rating for all intended applications is 300 volts. Consult the Canadian Electrical Code1 for further information related to applications.
| Jacket Color: Grey |
| Voltage: 300V |
